海康威视DS-B10视频综合平台安装手册

目录
1 安装准备.............................................................................................................................4
1.1 ..................................................................................................................4 注意事项
1.2 安装流程..................................................................................................................8
2 安装....................................................................................................................................9
2.1 拆卸挡板................................................................................................................10
2.2 主控板安装............................................................................................................10
2.3 业务板后接口板安装.............................................................................................10
2.4 业务板主板安装.....................................................................................................12
2.5 综合平台的机械安装.............................................................................................13
2.6 电源适配器安装及说明.........................................................................................15
2.6.1 电源适配器机柜安装..................................................................................15
2.6.2 电源适配器说明.........................................................................................16
2.6.3 电源接入.....................................................................................................17
2.7 线缆连接................................................................................................................19
2.7.1 连接视频综合平台调试口RS-232...............................................................19
2.7.2 连接视频综合平台的以太网口...................................................................19
2.7.3 音频线缆的连接方法..................................................................................19
3 日常维护...........................................................................................................................22
3.1 运行状态介绍及运行状态灯..................................................................................22
3.1.1 液晶屏状态.................................................................................................22
3.1.2前面板指示灯状态.......................................................................................22
3.2 清理维护................................................................................................................23
3.3 硬件更换................................................................................................................25
附录A 视频综合平台选配电缆说明.....................................................................................27
A1 以太网口接口电缆..................................................................................................27
A2 控制台接口电缆（RS-232配置口电缆）...............................................................27
附录B 设备安装中的电缆捆扎及电缆工程的标签...............................................................29
B1 布线工艺要求..........................................................................................................29
B2 电缆工程的标签......................................................................................................31
